3 VMA Mode

3.8 ACP Measurement

reference carrier and by testing the absolute power limit of the offset frequencies

(measured as total power in dB if "Measurement Type" on page 1330 is Total Pwr

Ref, or as power spectral density in dB if Measurement Type is PSD Ref).

When "Max Num of Offsets" on page 1285 is 6, returns 24 results (Offset A-F: 24 =

4*6). When set to 12, returns 48 results (Offset A-L: 48 = 4 * 12).

For MSR, LTE-Advanced FDD/TDD, and 5G NR Modes, this trace includes only outer

offset results.

# Item

1 Lower offset A - relative limit result

2 Lower offset A - absolute limit result

3 Upper offset A - relative limit result

4 Upper offset A - absolute limit result

5 Lower offset B - relative limit result

6 Lower offset B - absolute limit result

7 Upper offset B - relative limit result

8 Upper offset B - absolute limit result

... ...

If any result is not available, 1 is returned.

3.8.4 Measurement Results for n = 7

In all cases below:

–

for SA Mode, the values are in the current Y Axis Unit of the instrument

–

if any result is not available, 9.91E+37 (NaN) is returned

Mode Max Number of Carriers

MSR 100

LTEAFDD, LTEATDD 5

5GNR 16

All Others 18

Measurement Type = Total power reference

For the trace specified by "Measure Trace" on page 1755, returns (2 * Number of

Carriers) comma-separated scalar results in the following order:

# Channel Result Unit, if any

1 Channel (1) Relative power dB

2 Channel (1) Absolute power dBm

1163 Vector Modulation Analyzer Mode User's &Programmer's Reference
