7 Save/Recall/Print
7.3 Save
205
60047250.51
39215.68627
237
0
1.00E-07
1
2.36E-05
25
In addition, examples of the Meas Results files are given for each data type in the
Help below.
Remote
Command
:MMEMory:STORe:RESults <string>
Example
:MMEM:STOR:RES "MeasR_0000.csv"
Notes If the save is initiated via SCPI and the file already exists, the file will be overwritten
The SCPI command exports measurement results to the file specified as the parameter in the current
path. The default path is:
My Documents\<current mode>\data\<measurement name>\results
where <mode name> is the parameter used to select the mode with the :INST:SEL command (for
example, SA for Spectrum Analyzer Mode) and <measurement name> is the parameter used to
select the measurement with the :CONF: command (for example, SAN for the Swept SA
measurement)
Using the C: drive is strongly discouraged, since it runs the risk of being overwritten during an
instrument software upgrade
The SCPI parameter is a quoted string, which specifies the filename. Both single and double quotes
are supported for any filename parameter over SCPI
Annotation After the save is complete, an advisory is displayed in the window so that the user can confirm which
file was saved
Status Bits/OPC
dependencies
Sequential – waits for the previous measurement to complete
7.3.14 CHP Meas Results File Contents
The file contains measurement results, preceded by the following header
information.
–
File ID string, which is MeasResult
–
Mode ID: Measurement ID, for example, SA:CHP
2368 Vector Modulation Analyzer Mode User's &Programmer's Reference
