Keysight x-series Programmer's Reference

3 VMA Mode
3.8 ACP Measurement
Remote
Command
[:SENSe]:ACPower:OFFSet[1]|2:INNer:LIST:BANDwidth:VIDeo:AUTO OFF | ON | 0 |
1,…
[:SENSe]:ACPower:OFFSet[1]|2:INNer:LIST:BANDwidth:VIDeo:AUTO?
Subopcode: 1 = BTS/Downlink (Default), 2 = MS/Uplink
Example
:ACP:OFFS2:INN:LIST:BAND:VID:AUTO 0,0,0,0,1,1
:ACP:OFFS2:INN:LIST:BAND:VID:AUTO?
Preset When "Max Num of Offsets" on page 1285 is 12, the preset value of Offset G ~ L is ON
ON, ON, ON, ON, ON, ON
State Saved Yes
Filter Type
Selects the type of bandwidth filter that is used.
Remote Command
[:SENSe]:ACPower:OFFSet[1]|2:INNer:LIST:BANDwidth:SHAPe GAUSsian | FLATtop,…
[:SENSe]:ACPower:OFFSet[1]|2:INNer:LIST:BANDwidth:SHAPe?
Subopcode: 1 = BTS/Downlink (Default), 2 = MS/Uplink
Example
:ACP:OFFS2:INN:LIST:BAND:SHAP FLAT,GAUS,GAUS,GAUS,GAUS,GAUS
:ACP:OFFS2:INN:LIST:BAND:SHAP?
Dependencies When "Res BW" on page 1214 Mode for the offset is Auto, this cell is grayed-out and disabled. Since
Res BW Mode for the offset is preset to Auto on changing "Meas Method" on page 1246 to RBW,
FAST or Fast Power, this cell is grayed-out and disabled. If the cell is pressed, an advisory message is
generated. If the equivalent remote command is sent, a "Setting conflict" warning is generated
Preset When "Max Num of Offsets" on page 1285 is 12, the preset value of Offset G ~ L is GAUSsian
GAUSsian, GAUSsian, GAUSsian, GAUSsian, GAUSsian, GAUSsian
State Saved Saved in instrument state
Range
GAUSsian|FLATtop
Filter BW
Selects a Gaussian filter based on its –3 dB (Normal) bandwidth or its –6 dB
bandwidth.
Remote Command
[:SENSe]:ACPower:OFFSet[1]|2:INNer:LIST:BANDwidth:TYPE DB3 | DB6,…
[:SENSe]:ACPower:OFFSet[1]|2:INNer:LIST:BANDwidth:TYPE?
Subopcode: 1 = BTS/Downlink (Default), 2 = MS/Uplink
Example
:ACP:OFFS2:INN:LIST:BAND:TYPE DB3,DB3,DB3,DB3,DB3,DB3
:ACP:OFFS2:INN:LIST:BAND:TYPE?
Dependencies When "RBW Filter Type" on page 1217 is FLATtop or "Res BW" on page 1214 Mode for the offset is
1279 Vector Modulation Analyzer Mode User's &Programmer's Reference
