3 VMA Mode
3.9 SEM Measurement
Couplings Coupled to Abs Start if Auto is selected, that is, the Stop value is equal to the Start value
Preset 0dBm, 0 dBm, 0 dBm, 0 dBm, 0 dBm, 0 dBm, 0 dBm, 0 dBm, 0 dBm, 0dBm, 0 dBm, 0 dBm|0 dBm, 0
dBm, 0 dBm, 0 dBm, 0 dBm, 0 dBm, 0dBm, 0 dBm, 0 dBm, 0 dBm, 0 dBm, 0 dBm
ON, ON, ON, ON, ON, ON, ON, ON, ON, ON, ON, ON | ON, ON, ON, ON, ON, ON, ON,
ON, ON, ON, ON, ON
State Saved Saved in instrument state
Saved in instrument state
Range Auto|Man
Min -200 dBm
Max 50 dBm
Fail Mask2
Selects one of the logical operations for fail conditions between the measurement
results and the test limits:
(Primary Fail Mask
selection) OR Abs2
OR
Checks against both Primary and Abs2 limits. The test fails
if either of the limits is broken
(Primary Fail Mask
selection) AND Abs2
AND
Checks against both Primary and Abs2 limits. The test fails
if both of the limits are broken
Abs2 Disabled
OFF
Fail Mask2 is disabled
For examples, see "Fail Mask2" on page 1521.
Note that the Primary Fail Mask selection is set by "Fail Mask" on page 1541.
You can turn off (not use) specific inner offset channels remotely using:
[:SENSe]:SEMask:OFFSet[n]:INNer:LIST:STATe
When sending the command, missing values are not permitted; that is, if you want
to change values 2 and 6, you must send all values up to 6. Subsequent values
remain unchanged. The query always returns 12 values.
Remote
Command
[:SENSe]:SEMask:OFFSet[1]|2:INNer:LIST:TEST:SABSolute AND | OR | OFF, …
[:SENSe]:SEMask:OFFSet[1]|2:INNer:LIST:TEST:SABSolute?
Example
:SEM:OFFS:INN:LIST:TEST:SABS AND, AND, OR, OFF, OFF, OFF
:SEM:OFFS:INN:LIST:TEST:SABS?
Notes Comma-separated list of values
Preset
OFF, OFF, OFF, OFF, OFF, OFF, OFF, OFF, OFF, OFF, OFF, OFF | OFF, OFF, OFF,
OFF, OFF, OFF, OFF, OFF, OFF, OFF, OFF, OFF
State Saved Saved in instrument state
Range OR Abs2 | AND Abs2 | Abs2 Disabled
Vector Modulation Analyzer Mode User's &Programmer's Reference 1544
