3 VMA Mode

3.10 Spurious Emissions Measurement

+6.00000000E+000, +6.00000000E+000, +6.00000000E+000, +6.00000000E+000,

+6.00000000E+000, +6.00000000E+000, +6.00000000E+000, +6.00000000E+000

State Saved Saved in instrument state

Min/Max 0.0 dB/100.0 dB

Pk Threshold

Sets the minimum amplitude of signals that can be identified as peaks. For example,

if a value of -90dBm is selected, only peaks that rise and fall more than the peak

excursion value which are above –90dBm are identified.

This parameter can send up to 20 values. The location in the list sent corresponds to

the range of the associated value. When sending the remote command, missing

values are not permitted. If you want to change values 2 and 6, then you must send

all values up to 6. Subsequent values will remain as they were.

The query always returns 20 values.

Remote

Command

[:SENSe]:SPURious[:RANGe][:LIST]:PEAK:THReshold <real>, <real>, <real>,

<real>, <real>, <real>, <real>, <real>, <real>, <real>, <real>, <real>,

[:SENSe]:SPURious[:RANGe][:LIST]:PEAK:THReshold?

Example

:SPUR:PEAK:THR 0,0,0

:SPUR:PEAK:THR?

Preset -9.00000000E+001, -9.00000000E+001, -9.00000000E+001, -9.00000000E+001, -

9.00000000E+001, -9.00000000E+001, -9.00000000E+001, -9.00000000E+001, -

9.00000000E+001, -9.00000000E+001, -9.00000000E+001, -9.00000000E+001, -9.00000000E+001

,-9.00000000E+001 ,-9.00000000E+001, -9.00000000E+001, -9.00000000E+001, -

9.00000000E+001, -9.00000000E+001, -9.00000000E+001

State Saved Saved in instrument state

Min/Max -200/0

Meas Setup Summary Table

Lets you view and access many of the parameters in the Meas Setup menus on one

screen.

Auto Couple

Immediately puts all Auto/Man functions into Auto. Auto Couple is confined to the

current measurement only. It does not affect other measurements in the Mode.

In the Auto state, Auto/Man functions are said to be “coupled”, meaning their values

change as you make changes to other values in the measurement. This helps ensure

Vector Modulation Analyzer Mode User's &Programmer's Reference 1714
