3 VMA Mode
3.4 IQ Waveform Measurement
If you switch measurements with the display disabled (via :DISP:ENAB OFF), then query the list of
available Views, the result is undefined
User View Listing Query
Returns a string containing a comma-separated list of names for only the User
Views available for the current Measurement.
Remote
Command
:DISPlay:VIEW:ADVanced:USER:CATalog?
Example
:DISP:VIEW:ADV:USER:CAT?
Notes Returns a quoted string of the available User Views for the current measurement, separated by
commas.
Example:
"Baseband,myView1,yourView1"
If you switch measurements with the display disabled (see "Display Enable (Remote Command Only)"
on page 1812), then query the list of available Views, the result is undefined
3.4.5.2 Annotation
Contains controls for setting up the annotation for the current Mode or
Measurement.
Graticule
Turns the display graticule On or Off for all windows with graticules in all
measurements in the current Mode. Also turns the graticule Y-Axis annotation on
and off.
Remote
Command
:DISPlay:GRATicule[:STATe] OFF | ON | 0 | 1
:DISPlay:GRATicule[:STATe]?
Example
:DISP:GRAT OFF
Notes The graticule is the set of horizontal and vertical lines that make up the grid/divisions for the X-Axis and
Y-Axis
Preset
ON
State Saved Saved in instrument state
Backwards
Compatibility
SCPI
:DISPlay:WINDow[1]:TRACe:GRATicule:GRID[:STATe] OFF | ON | 0 | 1
:DISPlay:WINDow[1]:TRACe:GRATicule:GRID[:STATe]?
This command is accepted for backwards compatibility with older instruments, but the WINDow,
TRACe and GRID parameters are ignored
Vector Modulation Analyzer Mode User's &Programmer's Reference 734
