Keysight x-series Programmer's Reference

6 Input/Output
6.9 Calibration
6.9.1.34 Mech Atten Step
Determines the Mech Attenuation Step. This determines the points between the
Mechanical Attenuation min and max to use for Calibration.
Remote Command
:SYSTem:CALibration:ROW[1]|2|…|100:ATTenuation:STEP <rel_ampl>
:SYSTem:CALibration:ROW[1]|2|…|100:ATTenuation:STEP?
Example
:SYST:CAL:ROW2:ATT:STEP 2dB
Dependencies Disabled unless "Mech Atten Type" on page 2288 is STEP
The SCPI command applies to the currently selected Cal Group
If the subopcode does not reference an existing Cal row in the Cal Group, the error message “-221,
Settings conflict; Subopcode does not reference an existing Cal row” is generated
Preset 2dB
State Saved Saved in instrument state
Min 2dB
Max 10dB
6.9.1.35 Elec Atten Type
Specifies the Elec Atten type to use:
–
STEP: Use multiple Elec Atten states determined by Elec Atten Start, Elec Atten
Stop and Elec Atten Step
–
ALL: Use all the attenuator states
–
BYPass: Bypasses the attenuator
Remote Command
:SYSTem:CALibration:ROW[1]|2|…|100:EATTenuation:TYPE STEP | ALL | BYPass
:SYSTem:CALibration:ROW[1]|2|…|100:EATTenuation:TYPE?
Example
:SYST:CAL:ROW3:EATT:TYPE STEP
Dependencies The SCPI command applies to the currently selected Cal Group
If the subopcode does not reference an existing Cal row in the Cal Group, the error message “-221,
Settings conflict; Subopcode does not reference an existing Cal row” is generated
Preset
STEP
State Saved Saved in instrument state
Range
STEP|ALL|BYPass
6.9.1.36 Elec Atten Start
Determines the first Electronic Attenuator to be used in the Calibration
Vector Modulation Analyzer Mode User's &Programmer's Reference 2290
