3 VMA Mode
3.2 Custom OFDM Measurement
Interval Right
Lets you adjust the right side of the band. In order to remain centered in the band,
the marker position must also change as you change the right edge. The left edge is
unaffected.
Remote
Command
:CALCulate:OFDM:MARKer[1]|2|…|12:FUNCtion:INTerval:RIGHt <real>
:CALCulate:OFDM:MARKer[1]|2|…|12:FUNCtion:INTerval:RIGHt?
Example
:CALC:OFDM:MARK2:FUNC:INT:RIGHT 1.23E+06
:CALC:OFDM:MARK2:FUNC:INT:RIGHT?
Couplings Changes marker X to keep the marker centered in the band
Preset When marker turned on, 1/40
th
of current displayed time length right of the marker position
State Saved Yes
Min -9.9E+37
Max 9.9E+37
3.2.7.6 Marker To
The controls on this tab let you copy the current marker’s value into other
instrument parameters (for example, Center Frequency). The currently selected
marker is made the active function on entry to this menu (if the currently selected
marker is not on when you press this front panel key, it will be turned on at the
center of the screen as a Normal marker, then made the active function).
Marker X
Sets the X Axis value of the selected marker in the current X Axis Scale unit. It is the
same as "Marker X" on page 476 on the Settings tab.
Mkr -> CF
Sets the center frequency of the analyzer to the frequency of the selected marker.
The marker stays at this frequency, so it moves to the center of the display. In Delta
marker mode, this function sets the center frequency to the x-axis value of the delta
marker. When the frequency scale is in log mode, the center frequency is not at the
center of the display.
If the currently selected marker is not on when this control is pressed, it will be
turned on at the center of the screen as a Normal type marker.
Vector Modulation Analyzer Mode User's &Programmer's Reference 488
