3 VMA Mode

3.3 Monitor Spectrum Measurement

Note that if you are in External Mixing, the maximum Span will be equal to the

Maximum Stop Frequency – Minimum Start Frequency for the currently selected

mixer.

Span Presets by Mode

Mode Radio Std Preset Value

WCDMA 10.0 MHz

PN 1.0 MHz

GSM/EDGE 1.0 MHz

WLAN 802.11a/b/g/n/ac/ax/be (20 MHz) 25 MHz

802.11n/ac/ax/be (40MHz) 50 MHz

802.11ac/ax/be (80MHz) 100 MHz

802.11ac /ax/be (160MHz) 200 MHz

802.11be (320MHz) 400 MHz

MSR 20 MHz

LTEAFDD, LTEATDD 20 MHz

5GNR 150 MHz

RTS 40 kHz

CQM 10 MHz

CF Step

Changes the step size for the center frequency and start and stop frequency

functions. Once a step size has been selected and the center frequency function is

active, the step keys (and the UP|DOWN parameters for Center Frequency from

remote commands) change the center frequency by the step-size value. The step

size function is useful for finding harmonics and sidebands beyond the current

frequency span of the instrument.

Note that the start and stop frequencies also step by the CF Step value.

Remote Command

[:SENSe]:FREQuency:CENTer:STEP[:INCRement] <freq>

[:SENSe]:FREQuency:CENTer:STEP[:INCRement]?

[:SENSe]:FREQuency:CENTer:STEP:AUTO OFF | ON | 0 | 1

[:SENSe]:FREQuency:CENTer:STEP:AUTO?

Example

:FREQ:CENT:STEP 500 MHz

:FREQ:CENT UP

Increases the current center frequency value by 500 MHz

:FREQ:CENT:STEP?

:FREQ:CENT:STEP:AUTO ON

Vector Modulation Analyzer Mode User's &Programmer's Reference 628
