7 Save/Recall/Print

7.3 Save

–

Frequency Unit: Hz, kHz, MHz, GHz

–

Antenna Unit: dBuV/m, dBuA/m, dBG, dBpT, None

–

Frequency Interpolation: Logarithmic, Linear

7.3.51 Select Correction

Selects the specific Correction to be saved, for example, Correction 1.

Preset Not part of a Preset, but reset to Correction 1 by Restore Input/Output Defaults

Survives a shutdown

7.3.52 Saving a SCPI Recording as a Python Script

To execute the generated Python script:

–

Install the Python version required by PyVisa

–

Download the PyVisa library from: https://pypi.org/project/PyVISA/

–

Modify the connection string, to specify your instrument’s connection string

Example Script

An example of the generated script is shown below.

# _install location: https://pypi.org/project/PyVISA/

import pyvisa

import re

# connected instrument

_inst = ''

# SCPI Recording commands and queries

# Add/Modify the instrument address to execute the script

_connectionString = 'your instrument connection string here'

#Example SCPI Recording Entries

_recordingEntries = ['Active Mode & Measurement'|':INST:CONF:SA:SANalyzer',

'Query Operation Complete'|'*OPC?',

'Active Mode & Measurement'|':INST:CONF:SA:SANalyzer',

'Query Operation Complete'|'*OPC?',

Vector Modulation Analyzer Mode User's &Programmer's Reference 2407
