Keysight x-series Programmer's Reference

3 VMA Mode
3.9 SEM Measurement
Dependencies Grayed-out in VXT models M9410A/11A
Couplings If Sweep Type is set manually, Sweep Type mode is set to MANual
When Channel Sweep Type mode is Auto, Sweep Type is automatically selected according to Sweep
Type Rules
Preset Automatically calculated
ON
State Saved Saved in instrument state
Yes
Range
OFF|ON
Res BW
Sets the resolution bandwidth used to calculate the power in the reference channel.
The Channel Resolution BW can be set manually or put into auto mode.
MSR Auto RBW:
In the MSR Mode, resolution bandwidth is predefined for each radio format. When
carriers are configured with multiple radio formats, the narrowest RBW is selected.
Radio Format RBW (kHz)
LTE 1.4 MHz 13 kHz
3 MHz 27 kHz
5 MHz 47 kHz
10 MHz 91 kHz
15 MHz 150 kHz
20 MHz 180 kHz
200 kHz (NB-IoT, only available in FDD) 10 kHz
W-CDMA 75 kHz
5G NR Auto RBW:
Vector Modulation Analyzer Mode User's &Programmer's Reference 1554

Keysight x-series Specifications

General

Analysis Bandwidth	Up to 1 GHz (depending on model)
Real-Time Bandwidth	Up to 1 GHz (depending on model)
Form Factor	Benchtop
Connectivity	LAN, USB, GPIB
Resolution Bandwidth	1 Hz to 10 MHz (depending on model)
