Keysight x-series Programmer's Reference

3 VMA Mode
3.7 Power Stat CCDF Measurement
Name Unit Corresponding Results Results
Item for n =
1
Explanation
0.0001% dB Power level that has 0.0001%
of the power
8 99.99 dB
0.00001% dB Power level that has 0.00001%
of the power if "Minimum
Probability" on page 1075 is
PP7 (0.00001 %)
11 99.99 dB
Peak dB Peak power 9 99.99 dB
Peak dBm Not available via remote
commands
n/a 99.99 dBm
3.7.3 Amplitude
Activates the Amplitude menu and selects Reference Level or Reference Value as
the active function, depending on the measurement.
Some features in this menu apply to multiple measurements. Some other features
apply only to specific measurements and their controls are blanked or grayed-out in
measurements that do not support the feature.
3.7.3.1 Y Scale
Contains controls that pertain to the Y axis parameters of the measurement. These
parameters control how data on the vertical (Y) axis is displayed and control
instrument settings that affect the vertical axis.
Minimum Probability
Sets the minimum probability range.
Remote
Command
:CALCulate:PSTatistic:RANGe[:PROBability]:MINimum PP2 | … | PP7
For parameter values, see "Parameter Options" on page 1076 below
:CALCulate:PSTatistic:RANGe[:PROBability]:MINimum?
Example
:CALC:PST:RANG:MIN PP6
:CALC:PST:RANG:MIN?
Preset
PP6
State Saved Yes
Range 1 % | 0.1 % | 0.01 % | 0.001 %| 0.0001 % | 0.00001 %
1075 Vector Modulation Analyzer Mode User's &Programmer's Reference
