Keysight x-series Programmer's Reference

3 VMA Mode
3.5 Channel Power Measurement
3.5.5 Display
Lets you configure display items for the current Mode, Measurement View or
Window.
3.5.5.1 Meas Display
Contains controls for setting up the display for the current Measurement, View or
Window.
Bar Graph On/Off
Turns the Bar Graph On or Off.
Remote Command
:DISPlay:CHPower:WINDow[1]:BGRaph ON | OFF | 1 | 0
:DISPlay:CHPower:WINDow[1]:BGRaph?
Example
:DISP:CHP:WIND:BGR ON
:DISP:CHP:WIND:BGR?
Preset
OFF
State Saved Saved in instrument state
Range
ON|OFF
Backwards Compatibility
SCPI
:DISPlay:CHPower:VIEW[1]:WINDow[1]:BGRaph
3.5.5.2 Annotation
Contains controls for setting up the annotation for the current Mode or
Measurement.
Graticule
Turns the display graticule On or Off for all windows with graticules in all
measurements in the current Mode. Also turns the graticule Y-Axis annotation on
and off.
Remote
Command
:DISPlay:GRATicule[:STATe] OFF | ON | 0 | 1
:DISPlay:GRATicule[:STATe]?
Example
:DISP:GRAT OFF
Notes The graticule is the set of horizontal and vertical lines that make up the grid/divisions for the X-Axis and
Y-Axis
Vector Modulation Analyzer Mode User's &Programmer's Reference 852
