Keysight x-series Programmer's Reference

3 VMA Mode
3.8 ACP Measurement
Filter Type SCPI Example
Gaussian :BAND:SHAP GAUS
Flattop :BAND:SHAP FLAT
Remote Command
[:SENSe]:ACPower:BANDwidth:SHAPe GAUSsian | FLATtop
[:SENSe]:ACPower:BANDwidth:SHAPe?
Example
:ACP:BAND:SHAP GAUS
:ACP:BAND:SHAP?
Notes GAUSsian= Gaussian
FLATtop = Flattop
Dependencies Disabled when "Meas Method" on page 1246 is FAST or FPOWer
If pressed, an advisory message is generated. If the equivalent command is sent, a "Setting conflict"
warning is generated
Preset "Auto Couple" on page 1825 selects the preset value
State Saved Saved in instrument state
Annotation The annotation under RBW in the bottom left of the screen shows the type of filter or bandwidth that is
being used
Backwards
Compatibility SCPI
[:SENSe]:ACPower:BWIDth:SHAPe
RBW Filter BW
Selects a Gaussian filter based on its –3 dB (Normal) bandwidth or its –6 dB
bandwidth.
Remote Command
[:SENSe]:ACPower:BANDwidth:TYPE DB3 | DB6
[:SENSe]:ACPower:BANDwidth:TYPE?
Example
:ACP:BAND:TYPE DB3
:ACP:BAND:TYPE?
Dependencies Disabled when "RBW Filter Type" on page 1217 is FLATtop or "Meas Method" on page 1246 is
RBW, FAST, or Fast Power
If pressed, an advisory message is generated. If the equivalent command is sent, a "Setting conflict"
warning is generated
Preset
DB3
State Saved Saved in instrument state
Range –3 dB (Normal)|–6 dB
Backwards
Compatibility SCPI
[:SENSe]:ACPower:BWIDth:TYPE
Vector Modulation Analyzer Mode User's &Programmer's Reference 1218
