3 VMA Mode
3.2 Custom OFDM Measurement
Marker Settings Diagram
Lets you configure the Marker system using a visual utility. It is the same as "Marker
Settings Diagram" on page 479 on the Settings tab.
3.2.7.5 Marker Function
The controls on this tab let you control the Marker Functions of the instrument.
Marker Functions perform post-processing operations on marker data.
Marker X
Sets the X Axis value of the selected marker in the current X Axis Scale unit. It is the
same as "Marker X" on page 476 on the Settings tab.
Marker Function/Interval Function
Sets the marker control function type to one of the following:
NOISe Marker Noise
BPOWer Band Power/Interval Power
BDENsity Band Density/Interval Density
OFF Marker Function Off
Remote
Command
:CALCulate:OFDM:MARKer[1]|2|…|12:FUNCtion NOISe | BPOWer | BDENsity | OFF
:CALCulate:OFDM:MARKer[1]|2|…|12:FUNCtion?
Example
:CALC:OFDM:MARK:FUNC BPOW
:CALC:OFDM:MARK:FUNC?
Preset OFF
State Saved Yes
Range Marker Noise | Band Power | Band Density | Marker Function Off
Annotation Mkr # <X value> and <Marker value> upper right on graph
Band Span/Interval Span
Band Span
Sets the width of the span for the selected marker. This function defines the span of
frequencies. The marker position does not change when you adjust the span.
