7 Save/Recall/Print

7.2 Recall

Y(n) = + +

Y(n) is the predistorted signal, X(n) is the reference signal.

7.2.62 Loss Comp

Sets the import file type to Loss Compensation Before DUT Table or to Loss

Compensation After DUT Table.

Mode NFIGURE

Parameter Name Recall Loss Comp

Control Path Recall

Parameter Type ImmediateAction

SCPI Command

:MMEMory:LOAD:LOSS BEFore | AFTer,<file_name>

SCPI Example

:MMEM:LOAD:LOSS BEF,"C:\LossBefore.csv"

:MMEM:LOAD:LOSS AFT,"C:\LossAfter.csv"

Notes Three file formats are supported:

–

Loss Compensation file (.csv)

–

Legacy Loss Compensation file (.loss)

–

S parameter file (.s2p)

Soft Key Label Loss Comp

Backwards Compatibility SCPI :MMEMory:LOAD:LOSS

Initial S/W Revision A.04.00

For .s2p files, only the S21 component is used for the loss compensation.

The CSV format contains the following data:

File Type

Application Name: Measurement Name

Version and Model Number

Loss Comp Data

Below is an example of a valid CSV Loss Compensation file:

[Filetype LossCompensation]

[NF:NFIG]

Ver. ***, Model ***

10, 1.0000
