Keysight x-series Programmer's Reference

3 VMA Mode
3.2 Custom OFDM Measurement
Search Length
Specifies the amount or length of the Search Time input data that is included in the
measurement pulse search.
Remote
Command
[:SENSe]:OFDM:CCARrier0|…|7:TIME:LENGth:SEARch <time>
[:SENSe]:OFDM:OFDM:CCARrier0|…|7:TIME:LENGth:SEARch?
Example
:OFDM:CCAR0:TIME:LENG:SEAR 1ms
:OFDM:CCAR0:TIME:LENG:SEAR?
Preset 4 ms
State Saved Yes
Min Depends on Result Length
Max Depends on System BW
Result Length
Used to specify the amount of acquired time data (in symbols) that is available for
measurement analysis.
Remote
Command
[:SENSe]:OFDM:CCARrier0|…|7:TIME:LENGth:RESult <integer>
[:SENSe]:OFDM:CCARrier0|…|7:TIME:LENGth:RESult?
[:SENSe]:OFDM:CCARrier0|…|7:TIME:LENGth:RESult:AUTO OFF | ON | 0 | 1
[:SENSe]:OFDM:CCARrier0|…|7:TIME:LENGth:RESult:AUTO?
Example
:OFDM:CCAR0:TIME:LENG:RES 10
:OFDM:CCAR0:TIME:LENG:RES?
:OFDM:CCAR0:TIME:LENG:RES:AUTO ON
:OFDM:CCAR0:TIME:LENG:RES:AUTO?
Preset 60
ON
State Saved Yes
Yes
Range Auto|Man
Min 1
Max Depends on System BW
503 Vector Modulation Analyzer Mode User's &Programmer's Reference
