7 Save/Recall/Print

7.3 Save

7.3.73 Recording + State

You can save State and IQ recording into a snapshot file (*.rssf).

Remote Command

:MMEMory:STORe:RSTate <filename>

Example

:MMEM:STOR:RST "snapshot1.rssf"

Status Bits/OPC depend-

encies

Sequential - aborts the current measurement

7.3.74 Remote Only Commands

The following commands execute file system operations such as move, copy, and

transfer data from a file.

7.3.75 Mass Storage Catalog (Remote Command Only)

Remote

Command

:MMEMory:CATalog? [<directory_name>]

The string <directory_name> must be a valid logical path. If no string then it uses the current

directory

Example

:MMEM:CAT? "C:\"

Notes Queries disk usage information (drive capacity, free space available) and obtains a list of files and

directories in a specified directory in the following format:

<numeric_value>,<numeric_value>,\{<file_entry>\}

It returns two numeric parameters and as many strings as there are files and directories

The first parameter indicates the total amount of storage currently used in bytes

The second parameter indicates the total amount of storage available, also in bytes. <file_entry>

is a string. Each <file_entry> indicates the name, type, and size of one file in the directory list:

<file_name>,<file_type>,<file_size>

As the Windows file system has an extension that indicates file type, <file_type> is always empty.

<file_size> provides the size of the file in bytes. For directories, <file_entry> is surrounded

by square brackets and both <file_type> and <file_size> are empty

7.3.76 Mass Storage Change Directory (Remote Command Only)

Remote

Command

:MMEMory:CDIRectory [<directory_name>]

<directory_name> must be a valid logical path

:MMEMory:CDIRectory?

Vector Modulation Analyzer Mode User's &Programmer's Reference 2423
