6 Input/Output
6.1 RF Source
does not have enough space for all the waveform segments to be loaded, an error is generated and
none of the waveform segments is loaded
If ARB is ON, and you attempt to play a waveform sequence but not all the waveform segments within
the sequence could be found to be loaded into ARB memory, an error is generated. The selected
waveform keeps the previous value and ARB state remains On
If you specify a waveform segment via SCPI but the waveform segment is not present within ARB
playback memory, and cannot be found for auto loading within the current directory or the default
directory, an error is generatedand the file selection remains unchanged
If you select a waveform for playback and the waveform requires a license that is not installed on the
instrument, an error is generated
.
If ARB is ON and you load a file to ARB memory or delete a file from ARB memory, the playing waveform
segment may not keep phase continuity during the ARB memory operation. The waveform will be
replayed after the ARB operation is finished
Segments in ARB Memory
Shows you which files are loaded into the ARB memory and lets you select a file for
playback.
Recall Waveform
This is the same as Recall From File in the Recall, Waveform dialog.
Delete Segment From ARB Mem
This is the same as Delete Segment From ARB Mem in the Recall, Waveform dialog.
Delete All From ARB Memory
This is the same as Delete All From ARB Memory in the Recall, Waveform dialog.
Query ARB Memory File List (Remote Query Only)
Queries the test set for the list of waveform segments in the ARB memory.
NOTE
Returns a string for waveform segment names in ARB memory. If you require a
string list of waveform segments in the ARB memory, use "Query ARB Memory
Full File List (Remote Query Only)" on page 2096
2095 Vector Modulation Analyzer Mode User's &Programmer's Reference
