Keysight x-series Programmer's Reference

6 Input/Output
6.9 Calibration
6.9.1.7 Cal Input
Maps the currently selected Cal Group to a particular I/O port. This control allows
any Input port (including External Mixing, the RF2 input, etc.) to be mapped to a
specific Cal Group
Remote Command
:SYSTem:CALibration:INPut RFIN | RFIN2 || EMIXer | ERFIN
See "Option Details" on page 2277
:SYSTem:CALibration:INPut?
Example
:SYST:CAL:INPut RFIN2
Dependencies RFIN2|EMIXer are only available on C/E/M/P/UXA analyzers with the appropriate options loaded
ERFIN is only available if a V3050A unit is connected
State Saved Saved in State
Option Details
Note that the presence of these ports is highly hardware dependent.
Cal Input SCPI Notes
RF Input
RFIN
Main RF Port
Not available on EXM with hardware M9431A
RF Input 2
RFIN2
Second RF Port, labeled RF Input 2
Only available on certain instruments
External Mixer
EMIX
Requires option EXM
External RF
ERFIN
Only available if a V3050A unit is connected
6.9.1.8 Freq Offset
Specifies any frequency offset that is to be applied to the currently selected Cal
Group. This can be used when using an external mixer.
Remote Command
:SYSTem:CALibration:FREQuency:OFFSet <freq>
:SYSTem:CALibration:FREQuency:OFFSet?
Example
:SYST:CAL:FREQ:OFFS 1e9
Dependencies The query applies to the currently selected Cal Group
Preset All 0 Hz
State Saved Saved in instrument state
Min 0 Hz
Max 100.0 GHz
2277 Vector Modulation Analyzer Mode User's &Programmer's Reference
