6 Input/Output

6.5 Corrections

Min 0

Max 1 THz

6.5.5.3 Amplitude

Touching an amplitude value makes the touched row the current row and lets you

edit the amplitude.

Min -1000 dB

Max 1000 dB

6.5.5.4 Go to Row

Lets you move through the table to edit the desired point.

Min 1

Max 2000

6.5.5.5 Insert Row Below

Inserts a point below the current point. The new point is a copy of the current point

and becomes the current point. The new point is not yet entered into the underlying

table, and the data in the row is displayed in light gray. To enter the row into the

table, press the Enter key, or tap either value and edit it.

6.5.5.6 Delete Row

Deletes the currently-selected point, whether or not that point is being edited, and

selects the Navigate functionality. The point following the currently-selected point

(or the point preceding if there is none) will be selected.

6.5.5.7 Scale X Axis

Matches the X-Axis to the selected Correction, as well as possible. Sets the Start

and Stop Frequency to contain the minimum and maximum Frequency of the

selected Correction. The range between Start Frequency and Stop Frequency is

12.5% above the range between the minimum and maximum Frequency, so that

span exceeds this range by one graticule division on either side. If in zero-span, or

there is no data in the Ampcor table, or the frequency range represented by the

table is zero, no action is taken. Standard clipping rules apply if the value in the

table is outside the allowable range for the X-Axis.
