Keysight x-series Programmer's Reference

3 VMA Mode
3.2 Custom OFDM Measurement
Remote
Command
:DISPlay:OFDM:PILot:SUBCarrier OFF | ON | 0 | 1
:DISPlay:OFDM:PILot:SUBCarrier?
Example
:DISP:OFDM:PIL:SUBC 1
:DISP:OFDM:PIL:SUBC?
Preset ON
State Saved Yes
Range OFF|ON
Display Preamble Subcarriers
Enables/disables display of preamble subcarriers in IQ traces.
Remote
Command
:DISPlay:OFDM:PREamble:SUBCarrier OFF | ON | 0 | 1
:DISPlay:OFDM:PREamble:SUBCarrier?
Example
:DISP:OFDM:PRE:SUBC 1
:DISP:OFDM:PRE:SUBC?
Preset ON
State Saved Yes
Range OFF|ON
Display Sync Correlation in Percent
Enables/disables display of sync correlation values in percent. When true, sync
correlation values are displayed in percent.
Remote
Command
:DISPlay:OFDM:SYNC:CORRelation:PERCent OFF | ON | 0 | 1
:DISPlay:OFDM:SYNC:CORRelation:PERCent?
Example
:DISP:OFDM:SYNC:CORR:PERC 1
:DISP:OFDM:SYNC:CORR:PERC?
Preset OFF
State Saved Yes
Range OFF|ON
Display EVM in Percent (SCPI only)
Enables/disables display of EVM in percent. When false, the EVM values are
displayed in dB.
Remote Command
:DISPlay:OFDM:EVM:PERCent OFF | ON | 0 | 1
Vector Modulation Analyzer Mode User's &Programmer's Reference 466
