Keysight x-series Programmer's Reference

3 VMA Mode
3.5 Channel Power Measurement
Remote
Command
:DISPlay:CHPower:WINDow[1]:TRACe:Y[:SCALe]:COUPle 0 | 1 | OFF | ON
:DISPlay:CHPower:WINDow[1]:TRACe:Y[:SCALe]:COUPle?
Example
:DISP:CHP:WIND:TRAC:Y:COUP OFF
:DISP:CHP:WIND:TRAC:Y:COUP?
Couplings When Auto Scaling is ON, and the Restart front-panel key is pressed, this function automatically sets
the scale per division to 10dB and determines the reference values based on the measurement results
When you change the value of Scale/Div, Ref Value, or Scale Range, Auto Scaling automatically
changes to OFF
Preset 1
State Saved Saved in instrument state
Range
OFF|ON
Backwards
Compatibility
SCPI
:DISPlay:CHPower:VIEW[1]:WINDow[1]:TRACe:Y[:SCALe]:COUPle
3.5.3.2 Attenuation
Controls the attenuator functions and interactions between the attenuation system
components.
There are two attenuator configurations in the X-Series. One is a Dual-Attenuator
configuration consisting of a mechanical attenuator and an optional electronic
attenuator. The other configuration uses a single attenuator with combined
mechanical and electronic sections that controls all the attenuation functions.
Different models in the X-Series come with different configurations.
–
See "Dual-Attenuator Configurations" on page 808
–
See "Single-Attenuator Configuration" on page 808
Most attenuation settings are the same for all measurements – they do not change
as you change measurements. Settings like these are called “Meas Global” and are
unaffected by Meas Preset.
Only available when the hardware set includes an input attenuator, which is typically
only the case for Keysight’s benchtop instruments. For example, this tab does not
appear in VXT models M9420A/10A/11A/15A/16A, M9410E/11E/15E/16E, nor in
UXM. In UXM, all Attenuation and Range settings are disabled, as the expected
input power level is handled by the Call Processing App that drives the DUT power
control.
Dependencies In measurements that support the I/Q inputs, unavailable when I/Q is the selected input. Replaced by
the Range tab in that case
807 Vector Modulation Analyzer Mode User's &Programmer's Reference
