3 VMA Mode
3.8 ACP Measurement
Remote Command
:DISPlay:ACPower:VIEW:NSELect <integer>
For view numbers, see table above
:DISPlay:ACPower:VIEW:NSELect?
Example
:DISP:ACP:VIEW:NSEL 1
:DISP:ACP:VIEW:NSEL?
Dependencies Available only for LTEAFDD, LTEATDD and 5G NR Modes
Preset 1
State Saved Saved in instrument state
Min/Max 1 / 2
3.8.6.1 Normal
Windows: "Graph" on page 1167, "Metrics" on page 1168,
Dual window view of the graph and the metrics.
Example
:DISP:ACP:VIEW PRES
3.8.6.2 Carrier Info
Windows: "Graph" on page 1167, "Metrics" on page 1168,
Dual window view of the graph and the metrics.
Example
:DISP:ACP:VIEW CINF
3.8.7 Windows
This section describes the windows that are available in this measurement.
3.8.7.1 Graph
Window #1
Used to display the spectrum being measured by the ACP measurement.
The results of the measurement can be displayed as a single spectrum trace view or
displayed with a Bar Graph trace on the spectrum trace.
The Graph window appears in several Views, as follows:
1167 Vector Modulation Analyzer Mode User's &Programmer's Reference
