Keysight x-series Programmer's Reference

3 VMA Mode
3.2 Custom OFDM Measurement
Scale/Div
Controls the Y scale per division of the selected trace.
Remote Command
:DISPlay:OFDM:WINDow[1]|2|…|6:Y[:SCALe]:PDIVision <real>
:DISPlay:OFDM:WINDow[1]|2|…|6:Y[:SCALe]:PDIVision?
Example
:DISP:OFDM:WIND3:Y:PDIV 10
Set the Y scale/div of the third window to 10
:DISP:OFDM:WIND3:Y:PDIV?
Query the Y scale/div of the third window
Preset Depends on trace data
State Saved Yes
Min -9.9E+37
Max 9.9E+37
Annotation Upper left corner of trace grid, same gray as grid
Ref Position
Positions the reference level at the top, center, or bottom of the Y Scale display.
Changing the reference position does not change "Ref Value" on page 420.
Remote
Command
:DISPlay:OFDM:WINDow[1]|2|…|6:Y[:SCALe]:RPOSition TOP | CENTer | BOTTom
:DISPlay:OFDM:WINDow[1]|2|…|6:Y[:SCALe]:RPOSition?
Example
:DISP:OFDM:WIND3:Y:RPOS TOP
Set the Y ref position of the third window to TOP
:DISP:OFDM:WIND3:Y:RPOS?
Query the Y ref position of the third window
Preset Depends on trace data
State Saved Saved in instrument state
Range Top | Ctr | Bot
3.2.3.2 Attenuation
Controls the attenuator functions and interactions between the attenuation system
components.
There are two attenuator configurations in the X-Series. One is a Dual-Attenuator
configuration consisting of a mechanical attenuator and an optional electronic
attenuator. The other configuration uses a single attenuator with combined
421 Vector Modulation Analyzer Mode User's &Programmer's Reference
