Keysight x-series Programmer's Reference

3 VMA Mode
3.9 SEM Measurement
Radio Std Presets
160 MHz) dB, -40.00 dB
802.11be (320 MHz) -20.00 dB, -28.00 dB, -40.00 dB, -40.00 dB, -40.00 dB, -40.00 dB, -
40.00 dB, -40.00 dB, -40.00 dB, -40.00 dB, -40.00 dB, -40.00 dB, -40.00
dB, -40.00 dB
802.11ac/ax (80 MHz +
80MHz)
-40dB, -28.00 dB, -20.00 dB, 0 dB, -20.00 dB, -28.00 dB, -40.00 dB, -
40.00 dB, -40.00 dB, -40.00 dB, -40.00 dB, -40.00 dB, -40.00 dB, -40.00
dB
802.11ah (1MHz/ 2
MHz/ 4 MHz/ 8 MHz/
16 MHz)
-20.00 dB, -28.00 dB, -40.00 dB, -40.00 dB, -40.00 dB, -40.00 dB, -
40.00 dB, -40.00 dB, -40.00 dB, -40.00 dB, -40.00 dB, -40.00 dB, -40.00
dB, -40.00 dB
802.11 j/p 10M, p5M -20.00 dB, -28.00 dB, -40.00 dB, -40.00 dB, -40.00 dB, -47.00 dB, -
47.00 dB, -47.00 dB, -47.00 dB, -47.00 dB, -47.00 dB, -47.00 dB, -40.00
dB, -40.00 dB
802.11af (6MHz/
7MHz/ 8MHz)
-20.00 dB, -28.00 dB, -40.00 dB, -40.00 dB, -40.00 dB, -40.00 dB, -
40.00 dB, -40.00 dB, -40.00 dB, -40.00 dB, -40.00 dB, -40.00 dB, -40.00
dB, -40.00 dB
WLAN Mode Auto Function Presets
Radio Std Presets
802.11a/g (OFDM/DSSS-OFDM)
802.11n (20MHz/ 40MHz)
OFF, OFF, OFF, ON, ON, ON, ON, ON, ON, ON, ON,
ON, ON, ON
802.11b/g (DSSS/CCK/PBCC)
ON, ON, ON, ON, ON, ON, ON, ON, ON, ON, ON,
ON, ON, ON
802.11ac/ax/be (20 MHz/ 40 MHz/
80 MHz/ 160 MHz)
OFF, OFF, OFF, ON, ON, ON, ON, ON, ON, ON, ON,
ON, ON, ON
802.11be (320 MHz)
OFF, OFF, OFF, ON, ON, ON, ON, ON, ON, ON, ON,
ON, ON, ON
802.11ac/ax (80 MHz + 80MHz)
OFF, OFF, OFF, OFF, OFF, OFF, OFF, OFF, OFF,
OFF, OFF, OFF, OFF, OFF
802.11ah (1MHz/2 MHz/ 4 MHz/ 8
MHz/ 16 MHz)
OFF, OFF, OFF, ON, ON, ON, ON, ON, ON, ON, ON,
ON, ON, ON
802.11j/p (20M/ 10M) /11p(5M)
OFF, OFF, OFF, ON, ON, ON, ON, ON, ON, ON, ON,
ON, ON, ON
802.11af (6 MHz/ 7 MHz/ 8 MHz)
OFF, OFF, OFF, ON, ON, ON, ON, ON, ON, ON, ON,
ON, ON, ON
Fail Mask
Selects one of the logics for fail conditions between the measurement results and
the test limits:
1517 Vector Modulation Analyzer Mode User's &Programmer's Reference
