Keysight x-series Programmer's Reference

3 VMA Mode
3.2 Custom OFDM Measurement
Command
[:SENSe]:OFDM:CCARrier0|…|7:EFLock:RANGe:WIDTh?
Example
:OFDM:CCAR0:EFL:RANG:WIDT 10
:OFDM:CCAR0:EFL:RANG:WIDT?
Couplings Max value equals FFT Length
Preset 10
State Saved Saved in instrument state
Min 1
Max Depends on FFT Length
Phase Compensation Mode
Set the phase compensation mode on the baseband signal before upconversion.
AUTO Use the CF of current component carrier for symbol phase compensation
MANual Use the Phase Compensation Frequency for symbol phase compensation
OFF No symbol phase compensation
Remote
Command
[:SENSe]:OFDM:CCARrier0|…|7:PHASe:COMPensation:MODE AUTO | MANual | OFF
[:SENSe]:OFDM:CCARrier0|…|7:PHASe:COMPensation:MODE?
Example
:OFDM:CCAR0:PHAS:COMP:MODE AUTO
:OFDM:CCAR0:PHAS:COMP:MODE?
Preset OFF
State Saved Saved in instrument state
Phase Compensation Frequency
Set the phase compensation frequency on the baseband signal before
upconversion, when Phase Compensation Mode is MANual.
Remote
Command
[:SENSe]:OFDM:CCARrier0|…|7:PHASe:COMPensation:FREQuency <freq>
[:SENSe]:OFDM:CCARrier0|…|7:PHASe:COMPensation:FREQuency?
Example
:OFDM:CCAR0:PHAS:COMP:FREQ 1 GHz
:OFDM:CCAR0:PHAS:COMP:FREQ?
Preset 1 GHz
State Saved Saved in instrument state
Min 0
Max 100 GHz
Vector Modulation Analyzer Mode User's &Programmer's Reference 530
