6 Input/Output
6.9 Calibration
6.9.1.45 Frequency Extender Atten Step
Determines the Frequency Extender Attenuation Step. This determines the points
between the Frequency Extender Attenuation min and max to use for Calibration.
Remote Command
:SYSTem:CALibration:ROW[1]|2|…|100:FEATtenuation:STEP <rel_ampl>
:SYSTem:CALibration:ROW[1]|2|…|100:FEATtenuation:STEP?
Example
:SYST:CAL:ROW2:FEAT:STEP 2dB
Dependencies Only applies, and is only visible, when the External RF (ERFIN) input is selected
The SCPI command applies to the currently selected Cal Group
If the subopcode does not reference an existing Cal row in the Cal Group, the error message “-221,
Settings conflict; Subopcode does not reference an existing Cal row” is generated
Preset 1dB
State Saved No
Min 1dB
Max V3050A: 26 dB
6.9.1.46 IF Path
Determines the IF Path to be used in the Calibration.
Remote Command
:SYSTem:CALibration:ROW[1]|2|…|100:IF:PATH B10M | B25M | B40M | B85M |
B125M | B140M | B160M | B255M | B510M | B1G | B1500M | B2G | B4G | EXT
:SYSTem:CALibration:ROW[1]|2|…|100:IF:PATH?
Example
:SYST:CAL:ROW2:IF:PATH B25M
Notes
B10M
10 MHz
B25M
25 MHz
B40M
40 MHz
B85M
85 MHz
B125M
125 MHz
B140M
140 MHz
B160M
160 MHz
B255M
255 MHz
B510M
510 MHz
B1G
1 GHz
B1500M
1.5 GHz
B2G
2 GHz
Vector Modulation Analyzer Mode User's &Programmer's Reference 2296
