Keysight x-series Programmer's Reference

3 VMA Mode
3.2 Custom OFDM Measurement
Result Summary
Windows: "Demod Results" on page 418, "Burst Info" on page 418
Single window view consists of the above window.
Example
:DISP:OFDM:VIEW NRES
3.2.2 Windows
There are 6 window types available. Each window has three properties. The Data
and Format properties allow you to select the trace data and trace display format.
The Component Carrier property allows you to select the trace data of the CC to be
displayed. The Format selection is hidden if the selected Data doesn’t support any
format.
:DISPlay:OFDM:WINDow[1]|2|3|4|5|6:DATA <enum> is used to configure the trace
data. For example, the following command sets the first window data to Spectrum.
:DISP:OFDM:WIND1:DATA SPEC
:DISPlay:OFDM:WINDow[1]|2|3|4|5|6:FORMat <enum> is used to configure the trace
display format. For example, the following command sets the first window trace
display format to Constellation.
:DISP:OFDM:WIND1:FORM CONS
:DISPlay:OFDM:WINDow[1]|2|3|4|5|6:CC <enum> is used to configure the trace data
of the CC to be displayed. For example, the following command sets the CC0 trace
data to be displayed.
:DISP:OFDM:WIND1:CC 0
3.2.2.1 Data
Provides a menu of trace data choices for the selected window.
Remote
Command
:DISPlay:OFDM:WINDow[1]|2|…|6[:TRACe]:DATA RMTime | SPECtrum | MTIMe | RTIMe
| ERR3D | EVTime | EVSPectrum | CPERror | REVTime | REVSpectrum | CHFResponse
| EQIResponse | DRESults | BINFo | CESymbol | NONE
:DISPlay:OFDM:WINDow[1]|2|…|6[:TRACe]:DATA?
Example
:DISP:OFDM:WIND2:DATA SPEC
Sets the second window data to Spectrum
:DISP:OFDM:WIND2:DATA?
Couplings Depends on window
Preset Depends on window
413 Vector Modulation Analyzer Mode User's &Programmer's Reference

Keysight x-series Specifications

General

Analysis Bandwidth	Up to 1 GHz (depending on model)
Real-Time Bandwidth	Up to 1 GHz (depending on model)
Form Factor	Benchtop
Connectivity	LAN, USB, GPIB
Resolution Bandwidth	1 Hz to 10 MHz (depending on model)
