3 VMA Mode
3.5 Channel Power Measurement
RRC Filter BW
Sets the Root Raised Cosine (RRC) filter bandwidth. Normally, the filter bandwidth is
the same as the symbol rate of the signal.
Remote
Command
[:SENSe]:CHPower:FILTer[:RRC]:BANDwidth <real>
[:SENSe]:CHPower:FILTer[:RRC]:BANDwidth?
Example
:CHP:FILT:BAND 10MHz
:CHP:FILT:BAND?
Notes This parameter is normally used when TETRA is selected as the Radio Std
Preset SA, WCDMA, LTE, LTETDD Modes: 3.84MHz
WLAN Mode:
Radio Std Value
802.11a/g (OFDM/DSSS-OFDM) 16.6 MHz
802.11b 22 MHz
802.11n (20MHz) 17.8 MHz
802.11n (40MHz 36.6 MHz
State Saved Saved in instrument state
Min/Max 100 Hz / 100 MHz
Backwards
Compatibility
SCPI
[:SENSe]:CHPower:FILTer[:RRC]:BWIDth
3.5.8.3 Limits
Lets you set up the test limit for channel power or power spectral density.
When DVB-T radio standard is selected in SA Mode, this functionality is disabled,
and the input signal is instead compared against a pre-defined spectrum mask.
In LTE-A FDD/TDD and 5G NR Modes, this feature is not supported.
In MSR Mode, this feature is not supported, because the power of each carrier may
be different.
Power Limit
If Power Limit state is ON, this setting is a threshold to determine whether the real
measured channel power can be passed or not. If real measured channel power
exceeds Power Limit, the channel power test fails, otherwise, it passes.
If Power Limit state is OFF, the channel power test always passes.
Vector Modulation Analyzer Mode User's &Programmer's Reference 884
