Keysight x-series Programmer's Reference

3 VMA Mode
3.4 IQ Waveform Measurement
RF Envelope
Remote
Command
:DISPlay:WAVeform:VIEW[1]:WINDow[1]:TRACe:Y[:SCALe]:RANGe <rel_ampl>
:DISPlay:WAVeform:VIEW[1]:WINDow[1]:TRACe:Y[:SCALe]:RANGe?
Example
:DISP:WAV:VIEW:WIND:TRAC:Y:RANG 100
:DISP:WAV:VIEW:WIND:TRAC:Y:RANG?
Couplings Coupled to "Scale/Div" on page 678 as follows
Scale Range = Scale/Div * 10 (number of divisions)
When you change a value, "Auto Scaling" on page 681 automatically changes to OFF
Preset 100 dB
State Saved Saved in instrument state
Min 1
Max 200
IQ Waveform
Remote
Command
:DISPlay:WAVeform:VIEW2:WINDow[1]:TRACe:Y[:SCALe]:RANGe <voltage>
:DISPlay:WAVeform:VIEW2:WINDow[1]:TRACe:Y[:SCALe]:RANGe?
Example
:DISP:WAV:VIEW:WIND:TRAC:Y:RANG 1000
:DISP:WAV:VIEW:WIND:TRAC:Y:RANG?
Couplings Coupled to "Scale/Div" on page 678 as follows
Scale Range = Scale/Div * 10 (number of divisions)
When you change a value, "Auto Scaling" on page 681 automatically changes to OFF
Preset 1 V
State Saved Saved in instrument state
Min 10 nV
Max 200 V
Ref Position
Enables you to position the reference level at the top, center, or bottom of the Y
Scale display. Changing the reference position does not change the reference level
value.
The SCPI command and default parameters depend on whether the View is "RF
Envelope" on page 674 or "I/Q Waveform" on page 675.
Vector Modulation Analyzer Mode User's &Programmer's Reference 680
