3 VMA Mode
3.2 Custom OFDM Measurement
Ranges
Option Option # Phase Noise Option Range
No EPx Option 1 Best Close-in [offset < 20 kHz]
2 Best Wide-offset [offset > 30 kHz]
3 Fast Tuning [same as Best Close-In]
EP0 4 Best Close-in [offset < 600 kHz]
1 Balanced [offset < 600 kHz]
5 Best Spurs [offset < 600 kHz]
2 Best Wide-offset [offset > 800 kHz]
3 Fast Tuning [same as Best Close-In]
EP1 1 Best Close-in [offset < 140 kHz]
2 Best Wide-offset [offset > 160 kHz]
3 Fast Tuning [single loop]
EP2, EP3, EP5 1 Best Close-in [offset < 70 kHz]
2 Best Wide-offset [offset > 100 kHz]
3 Fast Tuning [medium loop bw]
EP4 1 Best Close-in [offset < 90 kHz]
2 Best Wide-offset [offset > 130 kHz]
3 Fast Tuning [same as Best Close-In]
Mixing Mode
Changes LO mixing from high-side to low-side or vice versa.
Remote Command
[:SENSe]:OFDM:CCARrier0|…|7:LO:MIXMode NORMal | ALTernate
[:SENSe]:OFDM:CCARrier0|…|7:LO:MIXMode?
Example
:OFDM:CCAR:LO:MIXM NORM
:OFDM:CCAR:LO:MIXM?
Dependencies Grayed-out when the RF Input is set to something other than “RF” (such as External Mixer). If you
press the grayed-out control, a warning message “Feature only available with Signal Input RF”
appears
If you try to set Mixing Mode via SCPI when disabled, a message -221,”Settings conflict; Feature only
available with signal input RF” is returned
Preset NORMal
State Saved Yes
Range NORMal | ALTernate
Vector Modulation Analyzer Mode User's &Programmer's Reference 544
