Keysight x-series Programmer's Reference

3 VMA Mode
3.11 Phase and Amplitude vs Time Measurement
Some features in this menu apply to multiple measurements. Some other features
apply only to specific measurements and their controls are blanked or grayed-out in
measurements that do not support the feature.
3.11.3.1 Y Scale
Contains controls that pertain to the Y axis parameters of the measurement. These
parameters control how data on the vertical (Y) axis is displayed and control
instrument settings that affect the vertical axis.
Scale
Selects the active scale for parameter adjustments of the menu.
Remote
Command
:DISPlay:PAVTime:VIEW[1]:WINDow[1]:TRACe:Y[:SCALe] AMPLitude | PHASe
:DISPlay:PAVTime:VIEW[1]:WINDow[1]:TRACe:Y[:SCALe]?
Example
:DISP:PAVT:VIEW:WIND:TRAC:Y AMPL
:DISP:PAVT:VIEW:WIND:TRAC:Y?
Preset
PHASe
State Saved Saved in instrument state
Range
Amplitude|Phase
Ref Value
The reference line is at the top, center, or bottom of the graticule, depending on the
value of "Ref Position" on page 1762.
Amplitude Scale
Sets the value for the reference position for the Amplitude Scale.
Remote
Command
:DISPlay:PAVTime:VIEW[1]:WINDow[1]:TRACe:Y[:SCALe]:AMPLitude:RLEVel <rel_
ampl>
:DISPlay:PAVTime:VIEW[1]:WINDow[1]:TRACe:Y[:SCALe]:AMPLitude:RLEVel?
Example
:DISP:PAVT:VIEW:WIND:TRAC:Y:AMPL:RLEV -10 dB
:DISP:PAVT:VIEW:WIND:TRAC:Y:AMPL:RLEV?
Preset Automatically calculated
State Saved Saved in instrument state
Min/Max -100/+100 dB
Annotation Ref <value> top of graph
Vector Modulation Analyzer Mode User's &Programmer's Reference 1760
