Keysight x-series Programmer's Reference

3 VMA Mode
3.9 SEM Measurement
Coupled with Channel Detector selection, Channel Sweep Time and Channel Video BW
When set to Auto, the resolution bandwidth is automatically calculated
Preset
Mode Values
SA 100kHz
WCDMA 75kHz
LTE, LTETDD, MSR, LTEAFDD, LTEATDD Auto (47kHz)
5G NR Auto
WLAN 100kHz
ON
State Saved Saved in instrument state
Saved in instrument state
Range Auto | Man
Min 1 Hz
Max When Option FS1 or FS2 is installed: 10 MHz
Otherwise: 8 MHz
Backwards
Compatibility
SCPI
[:SENSe]:SEMask:BWIDth[1]|2[:RESolution]
[:SENSe]:SEMask:BWIDth[1]|2[:RESolution]:AUTO
Video BW
Sets the video bandwidth used to calculate the power in the reference channel. The
Channel Video BW can be set manually or put into Auto mode.
Remote
Command
[:SENSe]:SEMask:BANDwidth[1]|2:VIDeo <bandwidth>
[:SENSe]:SEMask:BANDwidth[1]|2:VIDeo?
[:SENSe]:SEMask:BANDwidth[1]|2:VIDeo:AUTO OFF | ON | 1 | 0
[:SENSe]:SEMask:BANDwidth[1]|2:VIDeo:AUTO?
Example
:SEM:BAND:VID 100 kHz
:SEM:BAND:VID?
:SEM:BAND:VID:AUTO ON
:SEM:BAND:VID:AUTO?
Notes Bandwidth sub op code, 1 is for BTS, 2 for MS. Default is BTS
Note that Bandwidth sub op code 2 is supported only in non-SA Modes. In SA Mode, Bandwidth sub op
code 1 is used for both BTS and MS
Couplings If Video BW is set manually, Channel Video BW mode is set to MANual
Coupled with Channel Detector selection, Channel Sweep Time and Channel Resolution BW
When set to Auto, the video bandwidth is automatically calculated
Vector Modulation Analyzer Mode User's &Programmer's Reference 1556
