Keysight x-series Programmer's Reference

3 VMA Mode
3.1 Digital Demod Measurement
Example
:CALC:DDEM:SEGM1:COMP:IQOF ON
:CALC:DDEM:SEGM1:COMP:IQOF?
Dependencies Only available for IQ modulation format except FSK, ASK, CPM (FM) and DVB QAMs
Turned on automatically if the modulation format is changed to the formats except MSK Type1. For
MSK Type1 format, turned off automatically
Preset
ON
State Saved Yes
Backwards
Compatibility SCPI
:CALCulate:DDEMod:COMPensate:IQOFfset[:STATe]
Report EVM in DB
Remote
Command
[:SENSe]:DDEMod:SEGMent1|…|6:EVM:REPort:DB OFF | ON | 0 | 1
[:SENSe]:DDEMod:SEGMent1|…|6:EVM:REPort:DB?
Example
:DDEM:SEGM1:EVM:REP:DB ON
:DDEM:SEGM1:EVM:REP:DB?
Preset
OFF
State Saved Yes
Range
OFF|ON
Multi-Carrier Filter
Specifies whether or not to apply a filter to the acquisition IQ data to filter out
adjacent carriers.
When other carriers are expected to be adjacent to the carrier of interest, this multi-
carrier filter can be used to filter out the unwanted carrier and minimize leakage into
the carrier of interest.
Remote Command
[:SENSe]:DDEMod:SEGMent1|…|6:MCFilter:BANDwidth <freq>
[:SENSe]:DDEMod:SEGMent1|…|6:MCFilter:BANDwidth?
[:SENSe]:DDEMod:SEGMent1|2:MCFilter[:STATe] OFF | ON | 0 | 1
[:SENSe]:DDEMod:SEGMent1|2:MCFilter[:STATe]?
Example
:DDEM:SEGM1:MCF:BAND 50 kHz
:DDEM:SEGM1:MCF:BAND?
:DDEM:SEGM1:MCF OFF
:DDEM:SEGM1:MCF?
Dependencies The filter’s bandwidth cannot exceed the current information bandwidth
Preset 5 MHz
Vector Modulation Analyzer Mode User's &Programmer's Reference 350

Keysight x-series Specifications

General

Analysis Bandwidth	Up to 1 GHz (depending on model)
Real-Time Bandwidth	Up to 1 GHz (depending on model)
Form Factor	Benchtop
Connectivity	LAN, USB, GPIB
Resolution Bandwidth	1 Hz to 10 MHz (depending on model)
