3 VMA Mode

3.2 Custom OFDM Measurement

Ref Value

Controls the X value of the selected trace at the chosen X "Ref Position" on page

554.

Remote Command

:DISPlay:OFDM:WINDow[1]|2|…|6:X[:SCALe]:RLEVel <real>

:DISPlay:OFDM:WINDow[1]|2|…|6:X[:SCALe]:RLEVel?

Example

:DISP:OFDM:WIND3:X:RLEV 10

Set the X ref value of the third window to 10

:DISP:OFDM:WIND3:X:RLEV?

Query the X ref value of the third window

Couplings If "Auto Scaling" on page 554 is ON, X Ref Value is determined by the trace data

Preset Depends on trace data

State Saved Yes

Min -9.9E+37

Max 9.9E+37

Ref Position

Determines the position from which the X scaling is calculated for the selected

trace. It can be set to the left side, center, or right side of the grid.

Remote

Command

:DISPlay:OFDM:WINDow[1]|2|…|6:X[:SCALe]:RPOSition?

Example

:DISP:OFDM:WIND3:X:RPOS CENT

Set the X ref position of the third window to CENT

:DISP:OFDM:WIND3:X:RPOS?

Query the X ref position of the third window

Preset Depends on trace data

State Saved Yes

Range Left | Ctr | Right

Auto Scaling

Toggles this function On or Off.

Remote

Command

:DISPlay:OFDM:WINDow[1]|2|…|6:X[:SCALe]:COUPle 0 | 1 | OFF | ON

:DISPlay:OFDM:WINDow[1]|2|…|6:X[:SCALe]:COUPle?

Vector Modulation Analyzer Mode User's &Programmer's Reference 554
