Keysight x-series Programmer's Reference

3 VMA Mode
3.2 Custom OFDM Measurement
Remote Command
[:SENSe]:OFDM:CCARrier[0]|1|…|7:RF:CHANnel1|…|8:GAIN:PREamp OFF | LOW | FULL
[:SENSe]:OFDM:CCARrier[0]|1|…|7:RF:CHANnel1|…|8:GAIN:PREamp?
Example
:OFDM:CCAR0:RF:CHAN1:GAIN:PRE LOW
:OFDM:CCAR0:RF:CHAN1:GAIN:PRE?
Dependencies Preamp is not available on all hardware platforms. If the preamp is not present or is unlicensed, the
control is not shown
Preset OFF
State Saved Saved in instrument state
uW Path Control
Select uW Path for each component carriers.
Remote
Command
[:SENSe]:OFDM:CCARrier[0]|1|…|7:RF:CHANnel1|…|8:MW:PATH STD | LNPath |
MPBypass | FULL
[:SENSe]:OFDM:CCARrier[0]|1|…|7:RF:CHANnel1|…|8:MW:PATH?
Example
:OFDM:CCAR0:RF:CHAN1:MW:PATH LNP
:OFDM:CCAR0:RF:CHAN1:MW:PATH?
Preset MPB option present and licensed: MPB
MPB option not present and licensed: STD
State Saved Save in instrument state
Range Standard Path|Low Noise Path Enable|µW Presel Bypass|Full Bypass Enable
IF Gain
Set IF Gain for each component carriers.
Remote
Command
[:SENSe]:OFDM:CCARrier[0]|1|…|7:RF:CHANnel1|…|8:IF:GAIN:LEVel <rel_ampl>
[:SENSe]:OFDM:CCARrier[0]|1|…|7:RF:CHANnel1|…|8:IF:GAIN:LEVel?
Example
:OFDM:CCAR0:RF:CHAN1:IF:GAIN:LEV -10
:OFDM:CCAR0:RF:CHAN1:IF:GAIN:LEV?
Notes Not available for B25 IF bandwidth option
Preset 0
State Saved Save in instrument state
Min Depends on CC Bandwidth
Max Depends on CC Bandwidth
501 Vector Modulation Analyzer Mode User's &Programmer's Reference
