Keysight x-series Programmer's Reference

3 VMA Mode
3.6 Occupied BW Measurement
Example
:DISP:OBW:WIND:XDB 1
:DISP:OBW:WIND:XDB?
Preset 0
State Saved Saved in instrument state
Range
OFF|ON
Backwards Compatibility
SCPI
:DISPlay:OBWidth:VIEW:WINDow[1]:XDB
Boundary Frequency
Selects frequency display type:
–
OFFSet: offsets from Center Freq to OBW boundary frequency are displayed
–
ABSolute: absolute frequencies are displayed
Remote
Command
:DISPlay:OBWidth:WINDow2:BOUNdaries:FREQuency OFFSet | ABSolute
:DISPlay:OBWidth:WINDow2:BOUNdaries:FREQuency?
Example
:DISP:OBW:WIND2:BOUN:FREQ ABS
:DISP:OBW:WIND2:BOUN:FREQ?
Preset
OFFSet
State Saved Saved in instrument state
Range
OFFSet|ABSolute
Backwards
Compatibility
SCPI
:DISPlay:OBWidth:VIEW2:WINDow2:BOUNdaries:FREQuency
3.6.5.2 Annotation
Contains controls for setting up the annotation for the current Mode or
Measurement.
Graticule
Turns the display graticule On or Off for all windows with graticules in all
measurements in the current Mode. Also turns the graticule Y-Axis annotation on
and off.
Remote
Command
:DISPlay:GRATicule[:STATe] OFF | ON | 0 | 1
:DISPlay:GRATicule[:STATe]?
Example
:DISP:GRAT OFF
989 Vector Modulation Analyzer Mode User's &Programmer's Reference
