7 Save/Recall/Print
7.2 Recall
xSA Setup Files
Extension: xml
xSA Setup Files created by Signal Studio N7608C (Custom Modulation) or N7630C
(pre-5G) can be imported.
N7608C Setup Files
Extension: scp
Signal Studio N7608C (Custom Modulation) configuration file, when Custom
Modulation type is Custom OFDM.
89601 VSA Setup Files
Extension: set, setx
The 89600 Vector Signal Analyzer Setup file created using the 89600 Vector Signal
Analyzer Option BHF (Custom OFDM) can be imported. Note the resource map and
resource modulation information recalled from 89601 VSA Setup files is not
visible/editable under Meas Setup – Demod – Demod Settings - Resource Mapping.
Remote Command
:MMEMory:LOAD:OFDM:SETup ALL | CC0 | CC1 | CC2 | CC3 | CC4 | CC5 | CC6 |
CC7,<string>
Example
:MMEM:LOAD:OFDM:SET CC0,"mySetup.setx"
Dependencies Only appears in VMA Mode, in the Custom OFDM measurement
Annotation After recall is complete, an advisory is displayed in the message bar confirming the filter’s coefficients
were loaded
Status Bits/OPC
dependencies
Sequential - aborts the current measurement
7.2.42 Pilot IQ Values
Selects a CSV file from which to import the Pilot IQ Values. Note the CSV file for
MIMO contains IQ data for multiple layers, so the format is different than SISO.
Remote Command
:MMEMory:LOAD:OFDM:IQPilot CC0 | … | CC7,<filename>
Example
:MMEM:LOAD:OFDM:IQP CC0,"pilotIQ.csv"
Dependencies Only appears in VMA Mode, in the Custom OFDM measurement
Status Bits/OPC
dependencies
Sequential - aborts the current measurement
7.2.43 Preamble IQ Values
Selects a CSV file from which to import the Preamble IQ Values. Note the CSV file
for MIMO contains IQ data for multiple layers, so the format is different than SISO.
Vector Modulation Analyzer Mode User's &Programmer's Reference 2343
