Keysight x-series Programmer's Reference

3 VMA Mode
3.6 Occupied BW Measurement
3.6.1.2 OBW Boundaries
Windows: "Graph" on page 937, "Metrics - OBW Boundaries" on page 940
The spectrum trace is displayed in the upper window. The lower window of OBW
Results view is replaced by the OBW boundaries table in this view. Occupied
bandwidth and X dB bandwidth for both lower and upper boundaries are displayed.
Example
:DISP:OBW:VIEW BOUN
3.6.1.3 Gate
See "Gate View On/Off" on page 2484
3.6.2 Windows
There are four available window types. The Gate window is available only when
"Gate View On/Off" on page 2484 is ON in the Gate Settings menu under Trigger.
View #
"Graph" on page 937 1
"OBW Results" on page 936 2
"OBW Boundaries" on page 937 3
"Gate" on page 941 4
3.6.2.1 Graph
Window #1
Appears in two Views, as follows:
View Size Position
"OBW Results" on page 936 Three fifth, full width Top
"OBW Boundaries" on page 937 Half, full width Top
Spectrum View
For SA, WCDMA, WLAN mode:
937 Vector Modulation Analyzer Mode User's &Programmer's Reference

Keysight x-series Specifications

General

Analysis Bandwidth	Up to 1 GHz (depending on model)
Real-Time Bandwidth	Up to 1 GHz (depending on model)
Form Factor	Benchtop
Connectivity	LAN, USB, GPIB
Resolution Bandwidth	1 Hz to 10 MHz (depending on model)
