3 VMA Mode
3.10 Spurious Emissions Measurement
with the computed values being clipped to a minimum of 601 and a maximum of
20001.
Remote
Command
[:SENSe]:SPURious[:RANGe][:LIST]:SWEep:POINts <integer>
[:SENSe]:SPURious[:RANGe][:LIST]:SWEep:POINts?
Example
:SPUR:SWE:POIN 1001,1001,1001
:SPUR:SWE:POIN?
Preset SA, 5G NR Modes: +601, +601, +601, +601, +601, +601, +601, +601, +601, +601, +601, +601, +601,
+601, +601, +601, +601, +601, +601, +601
WCDMA Mode: 601, 2985, 9700, 1100, 601, 601, 601, 10570, 601, 601, 601, 601, 601, 601, 601, 601,
601, 601, 601, 601
LTE, LTETDD, LTEAFDD, LTEATDD, WLAN, MSR Modes: Automatically calculated
State Saved Saved in instrument state
Min/Max 101/20001
Auto Function
Remote
Command
[:SENSe]:SPURious[:RANGe][:LIST]:SWEep:POINts:AUTO OFF | ON | 0 | 1, OFF | ON
| 0 | 1, OFF | ON | 0 | 1, OFF | ON | 0 | 1, OFF | ON | 0 | 1, OFF | ON | 0 |
1, OFF | ON | 0 | 1, OFF | ON | 0 | 1, OFF | ON | 0 | 1, OFF | ON | 0 | 1,
OFF | ON | 0 | 1, OFF | ON | 0 | 1, OFF | ON | 0 | 1, OFF | ON | 0 | 1, OFF |
ON | 0 | 1, OFF | ON | 0 | 1, OFF | ON | 0 | 1, OFF | ON | 0 | 1, OFF | ON |
0 | 1, OFF | ON | 0 | 1
[:SENSe]:SPURious[:RANGe][:LIST]:SWEep:POINts:AUTO?
Example
:SPUR:SWE:POIN:AUTO ON,ON,ON
:SPUR:SWE:POIN:AUTO?
Preset
Modes Values
LTEAFDD,
LTEATDD,
MSR
ON, ON, ON, ON, ON, ON, ON, ON, ON, ON, ON, ON, ON, ON, ON,
ON, ON, ON, ON, ON
All others
OFF, OFF, OFF, OFF, OFF, OFF, OFF, OFF, OFF, OFF, OFF, OFF,
OFF, OFF, OFF, OFF, OFF, OFF, OFF, OFF
State Saved Saved in instrument state
Range
OFF|ON
Detector 1
Sets the detector to be used by the trace for spur detection and limit line testing.
Remote
Command
[:SENSe]:SPURious[:RANGe][:LIST]:DETector[1][:FUNCtion] AVERage | NEGative |
NORMal | POSitive | SAMPle | RMS, AVERage | NEGative | NORMal | POSitive |
SAMPle | RMS, AVERage | NEGative | NORMal | POSitive | SAMPle | RMS, AVERage
Vector Modulation Analyzer Mode User's &Programmer's Reference 1708
