Keysight x-series Programmer's Reference

3 VMA Mode
3.4 IQ Waveform Measurement
Valid Measurement Keywords
This function is available only in certain Modes and measurements. Only the
following listed values of <meas> are valid.
Mode(s) Meas
<meas>
BASIC
Complex Spectrum
SPECtrum
BASIC
CQM
EDGEGSM
LTEAFDD
LTEATDD
MSR
NR5G
PNOISE
SRCOMMS
VMA
WCDMA
WLAN
IQ Waveform
WAVeform
WLAN
Modulation Analysis
EVM
WLAN
MIMO Modulation Analysis
EVMMimo
Mixing Mode State (Remote Command Only)
Available only in the Complex Spectrum, Streaming, and Waveform measurements.
Lets you alternate between mixing modes for the Local Oscillator (LO). The default
setting is NORMal LO mixing mode, which is determined by the instrument
configuration to be either “high side” or “low side”. The query returns “High” or
“Low” to determine whether the mixing is “high side” or “low side”. If Mixing Mode is
toggled between NORMal and ALTernate, then Mixing Mode State also toggles
between “High” and “Low”.
Remote Command
[:SENSe]:SPECtrum:LO:MIXMode:SIDE?
[:SENSe]:WAVeform:LO:MIXMode:SIDE?
Example
:SPEC:LO:MIXM:SIDE?
:WAV:LO:MIXM:SIDE?
Dependencies Not available in N9000B
Couplings When Mixing Mode is toggled between NORMal and ALTernate, Mixing Mode State also toggles
Vector Modulation Analyzer Mode User's &Programmer's Reference 780

Keysight x-series Specifications

General

Analysis Bandwidth	Up to 1 GHz (depending on model)
Real-Time Bandwidth	Up to 1 GHz (depending on model)
Form Factor	Benchtop
Connectivity	LAN, USB, GPIB
Resolution Bandwidth	1 Hz to 10 MHz (depending on model)
