Keysight x-series Programmer's Reference

7 Save/Recall/Print
7.3 Save
This command works only when the measurement is in Single mode (see
"Sweep/Measure" on page 1830). When the command is sent, it blocks the SCPI
client, waits for the current refresh to complete, then captures the screen shot and
saves it. In some instances, a single measurement is taken, and a screen shot of that
measurement is captured.
This command ensures that the last-measured data is refreshed on the screen
before it is captured, by blocking the command and waiting for refresh to complete.
The command may time out, in which case it must be re-sent.
If timeout occurs, or if the active measurement is in Continuous mode, an error is
returned.
Remote
Command
:MMEMory:STORe:SCReen:BLOCked <filename>
Example Wait for the current screen refresh to complete before capturing the screen shot, then store the current
screen image in the file MyScreenFile.png in the default directory:
:MMEM:STOR:SCR:BLOC "myScreen.png"
7.3.68 Theme
Accesses a menu of functions that enable you to choose the theme to be used when
saving the screen image. You can choose between themes to be used when saving
the screen image.
See "More Information" on page 2419 for examples of the themes.
Remote
Command
:MMEMory:STORe:SCReen:THEMe FILLed | OUTLine
:MMEMory:STORe:SCReen:THEMe?
Example
:MMEM:STOR:SCR:THEM OUTL
Preset FILLed; not part of Preset, but reset by Restore Misc Defaults or Restore System Defaults All
Backwards
Compatibility
SCPI
:MMEMory:STORe:SCReen:THEMe TDColor | TDMonochrome | FCOLor | FMONochrome
Backwards
Compatibility
Notes
To permit code compatibility with A-model X-Series Signal Analyzer instruments, the command
parameters from the A-models are mapped as follows:
TDColor and TDMonochrome are both mapped to FILLed
(exact full color representation of what is on the screen)
FCOLor and FMONochrome are both mapped to OUTLine
(uses color for traces and other items, but most filled areas are white)
There is no Monochrome theme in B-models, so the A-models monochrome commands yield color
:MMEM:STOR:SCR:THEM? always returns FILLed or OUTLine, never FCOLor, FMONochrome,
TDColor, or TDMonochrome
There is no monochrome theme in the X-Series Touch UI
More Information
Vector Modulation Analyzer Mode User's &Programmer's Reference 2419
