Keysight x-series Programmer's Reference

3 VMA Mode
3.4 IQ Waveform Measurement
Enable High Freq Prefilter for the Swept SA Measurement in SA Mode:
:SAN:PFIL ON
Dependencies Only appears in VXT models M9410A/11A with center frequency above 1310MHz, and M9410E/11E
in frequency range 1310MHz~5GHz
Preset See "Prefilter Presets" on page 724 below
State Saved Saved in instrument state
Prefilter Presets
Meas Mode Preset
SPEC BASIC OFF
WAV BASIC, WCDMA, WLAN, LTEAFDD, LTEATDD, 5GNR, VMA OFF
MON WCDMA, WLAN, LTEAFDD, LTEATDD, 5GNR, VMA OFF
RHO WCDMA OFF
CDP WCDMA OFF
PCON WCDMA OFF
EVMQ WCDMA OFF
CHP WCDMA, WLAN, LTEAFDD, LTEATDD, 5GNR, VMA, SA OFF
OBW WCDMA, WLAN, LTEAFDD, LTEATDD, 5GNR, VMA, SA OFF
ACP WCDMA, LTEAFDD, LTEATDD, 5GNR, VMA, SA OFF
SEM WCDMA, WLAN, LTEAFDD, LTEATDD, 5GNR, VMA, SA OFF
PST WCDMA, WLAN, LTEAFDD, LTEATDD, 5GNR, VMA, SA OFF
PVT WLAN, LTEAFDD, LTEATDD, 5GNR OFF
EVM WLAN, LTEAFDD, LTEATDD, 5GNR OFF
FLAT WLAN OFF
EVMM WLAN OFF
CEVM LTEAFDD, LTEATDD OFF
PAVT 5GNR, VMA OFF
DDEM VMA OFF
OFDM VMA OFF
SAN SA ON
HARM SA ON
3.4.4 BW
Opens the BW (Bandwidth) menu. The Digital IF BW functions control filter
bandwidth and filter type. There are two filter types: Gaussian and Flattop. The
Gaussian filters have a response curve that is parabolic on a log scale. The Flattop
filter shape is a close approximation of a rectangular filter.
Vector Modulation Analyzer Mode User's &Programmer's Reference 724

Keysight x-series Specifications

General

Analysis Bandwidth	Up to 1 GHz (depending on model)
Real-Time Bandwidth	Up to 1 GHz (depending on model)
Form Factor	Benchtop
Connectivity	LAN, USB, GPIB
Resolution Bandwidth	1 Hz to 10 MHz (depending on model)
