Keysight x-series Programmer's Reference

6 Input/Output
6.1 RF Source
Entering a Channel
If the Band selection for the current row is not NONE, enter a Channel Number. This
field in the table allows you to select the channel value for the current step. The
frequency is selected automatically, based on the Band.
Example
:SOUR:LIST:STEP2:SET:CNFR 124
:SOUR:LIST:STEP2:SET:CNFR?
Notes SCPI is supported after A.09.40
Used to setup channel number or frequency setting, according to current Radio Band setting. If Radio
Band is NONE, then the value is a frequency. If Radio Band is not NONE, then the value is a channel
number
Dependencies Not available in E7760B
Couplings The channel number is coupled to the step frequency value. When the step frequency value is
changed, the channel number increases or decreases to match the new step frequency. If the step
frequency is not at an exact match for a channel number, the nearest channel number is displayed,
along with a greater-than or less-than sign, to indicate the frequency is above or below the channel
number
Preset 1
Min/Max 0/10838 (See "Channel" on page 2053 for valid ranges)
Power
Lets you specify the power value for the current step.
Remote Command
:SOURce:LIST:STEP[1]|2|…|1000:SETup:AMPLitude <double>
:SOURce:LIST:STEP[1]|2|…|1000:SETup:AMPLitude?
Example
:SOUR:LIST:STEP2:SET:AMPL -50dBm
:SOUR:LIST:STEP2:SET:AMPL?
Dependencies The RF power is dependent on the RF output port and frequency, such that the current frequency and
selected output port determine the valid range of power values
Not available in E7760B
Preset -100 dBm
Min/Max The range of values depends on the current frequency and selected RF output port
See "RF Power" on page 2018 and the RF Power Range table for valid ranges
Waveform
Lets you select the waveform to be played back during the current step. Options are:
CW, a Waveform file, Continue the previous step’s waveform, or Off.
Remote Command
:SOURce:LIST:STEP[1]|2|…|1000:SETup:WAVeform <string>
2037 Vector Modulation Analyzer Mode User's &Programmer's Reference
