Keysight x-series Programmer's Reference

6 Input/Output
6.1 RF Source
Options
Parameter Notes
OFF
This model is not listed in the Secondary module List
SECondary
Use :SOURce:SYNC:CONNected:NAME? to obtain the Primary’s name in Sync State
PRIMary
Sync Setup is only available for Primary
6.1.13.3 Sync Settings
Grayed-out when Primary and Secondary are in Sync State.
Dependencies Grayed-out when Sync Type is set to OFF or Secondary
Secondary Module List
Lists the parameters of Secondary modules. The Selected checkbox in each row
allows you to select the Secondary module when the Sync Type is set to Primary.
–
When Sync Config is set to NxN, use this control to enable N-1 Secondary
modules
–
When Sync Config is set to NxN+NxN, use this control to enable 2N-1 Secondary
modules
See "More Information" on page 2114
Remote
Command
:SOURce:SYNC:REMote:SECondary<integer> ON | OFF | 1 | 0
:SOURce:SYNC:REMote:SEC<integer>?
Example
:SOUR:SYNC:REM:SEC1 ON
:SOUR:SYNC:REM:SEC2 OFF
Notes <integer> Secondary module number in Available Models
Preset
OFF
More Information
Parameter SCPI Example Notes
Available Secondary
modules
:SOUR:SYNC:REM:SEC:List? All the available Secondary models are listed
IP Address :SOUR:SYNC:REM:SEC1:ADDR? Refer to Remote Chassis to add the IP Address for remote
chassis
Vector Modulation Analyzer Mode User's &Programmer's Reference 2114
