Keysight x-series Programmer's Reference

3 VMA Mode
3.9 SEM Measurement
3.9.19.2 X Scale
Accesses controls that enable you to set the horizontal scale parameters.
Ref Value
Sets the X reference value.
Remote
Command
:DISPlay:SEMask:WINDow[1]:TRACe:X[:SCALe]:RLEVel <freq>
:DISPlay:SEMask:WINDow[1]:TRACe:X[:SCALe]:RLEVel?
Example
:DISP:SEM:WIND:TRAC:X:RLEV 10
:DISP:SEM:WIND:TRAC:X:RLEV?
Couplings If "Auto Scaling" on page 1420 is ON, this value is automatically determined by the measurement result.
If you set this value manually, Auto Scaling automatically changes to OFF
Preset 1.0 GHz
State Saved Saved in instrument state
Min -1000 GHz
Max 1000 GHz
Backwards
Compatibility
SCPI
:DISPlay:SEMask:VIEW[1]:WINDow[1]:TRACe:X[:SCALe]:RLEVel
Scale/Div
Sets the horizontal scale.
Remote
Command
:DISPlay:SEMask:WINDow[1]:TRACe:X[:SCALe]:PDIVision <freq>
:DISPlay:SEMask:WINDow[1]:TRACe:X[:SCALe]:PDIVision?
Example
:DISP:SEM:WIND:TRAC:X:PDIV 500
:DISP:SEM:WIND:TRAC:X:PDIV?
Couplings If Auto Scaling is ON, this value is automatically determined by the measurement result. When you set
this value manually, Auto Scaling automatically changes to OFF
Preset Automatically Calculated
State Saved Yes Saved in instrument state
Min 1 Hz
Max 100 GHz
Backwards
Compatibility
SCPI
:DISPlay:SEMask:VIEW[1]:WINDow[1]:TRACe:X[:SCALe]:PDIVision
1581 Vector Modulation Analyzer Mode User's &Programmer's Reference
