3 VMA Mode
3.11 Phase and Amplitude vs Time Measurement
Phase Scale
Sets the value for the reference position for the Phase Scale. The reference line is at
the top, center, or bottom of the graticule, depending on the value of Ref Position.
Remote
Command
:DISPlay:PAVTime:VIEW[1]:WINDow[1]:TRACe:Y[:SCALe]:PHASe:RLEVel <real>
:DISPlay:PAVTime:VIEW[1]:WINDow[1]:TRACe:Y[:SCALe]:PHASe:RLEVel?
Example
:DISP:PAVT:VIEW:WIND:TRAC:Y:PHAS:RLEV 90
:DISP:PAVT:VIEW:WIND:TRAC:Y:PHAS:RLEV?
Preset Automatically calculated
State Saved Saved in instrument state
Min/Max -1000/+1000
Annotation Ref <value> / top of graph
Scale/Div
Sets the units per division in the graph window.
Amplitude Scale
Sets the units per division of the amplitude vertical scale in the graph window.
Remote
Command
:DISPlay:PAVTime:VIEW[1]:WINDow[1]:TRACe:Y[:SCALe]:AMPLitude:PDIVision <rel_
ampl>
:DISPlay:PAVTime:VIEW[1]:WINDow[1]:TRACe:Y[:SCALe]:AMPLitude:PDIVision?
Example
:DISP:PAVT:VIEW:WIND:TRAC:Y:AMPL:PDIV 5
:DISP:PAVT:VIEW:WIND:TRAC:Y:AMPL:PDIV?
Preset Automatically calculated
State Saved Saved in instrument state
Range 0.10 dB to 20.00 dB
Min 0.10 dB
Max 20.00 dB
Annotation <value> dB/ left upper of graph
Phase Scale
Sets the units per division of the phase vertical scale in the graph window.
Remote
Command
:DISPlay:PAVTime:VIEW[1]:WINDow[1]:TRACe:Y[:SCALe]:PHASe:PDIVision <real>
:DISPlay:PAVTime:VIEW[1]:WINDow[1]:TRACe:Y[:SCALe]:PHASe:PDIVision?
Example
:DISP:PAVT:VIEW:WIND:TRAC:Y:PHAS:PDIV 5
1761 Vector Modulation Analyzer Mode User's &Programmer's Reference
