Keysight x-series Programmer's Reference

6 Input/Output
6.1 RF Source
VXT models M9415A/16A
RF Output
Port
Frequency
Range
Min Output
Power
Max Output Power
without Option “1EA”
Max Output Power
with Option “1EA”
RF Output 380 MHz ≤ f ≤
12.3 GHz
–150 dBm 5 dBm 25 dBm
RFHD 380 MHz ≤ f ≤
12.3 GHz
–150 dBm 5 dBm 18 dBm
Note 1: For RF output port, the Max output power with Option 1EA can be set to 25
dBm for RF Output Port, but Meas Uncal (measurement uncalibrated) warning is
given in the Status Bar in the lower right corner of the screen when the output
power is set higher than 20 dBm.
Note 2: For RFHD port, the Max output power with Option 1EA can be set to 18 dBm
for RF Output Port, but Meas Uncal (measurement uncalibrated) warning is given in
the Status Bar in the lower right corner of the screen when the output power is set
higher than 15 dBm.
M9410E/11E/15E/16E
Ports Option LFE Frequency Range Min Output
Power
Max Output
Power
RF Output With Option LFE 1 MHz ≤ f ≤ 380 MHz -150 dBm 13 dBm
380 MHz ≤ f ≤ 25.9
GHz
-150 dBm 25 dBm
Without Option
LFE
380 MHz ≤ f ≤ 25.9
GHz
-150 dBm 25 dBm
RFHD 1 MHz ≤ f ≤ 25.9 GHz -150 dBm 5 dBm
VXT Models with Remote Radio Heads/CIU
RRH Port Frequency Range Min Output
Power
Max Output
Power
M1742A Head h RFHD
p
10 GHz ≤ f ≤ 32
GHz
–150 dBm 10 dBm
2021 Vector Modulation Analyzer Mode User's &Programmer's Reference

Keysight x-series Specifications

General

Analysis Bandwidth	Up to 1 GHz (depending on model)
Real-Time Bandwidth	Up to 1 GHz (depending on model)
Form Factor	Benchtop
Connectivity	LAN, USB, GPIB
Resolution Bandwidth	1 Hz to 10 MHz (depending on model)
