Rate-type: The rate type of the queue shaper. The allowed values are:
Line: Specify that this shaper operates on line rate.
Data: Specify that this shaper operates on data rate.
Credit: Check the box if you want the queue to have credit-based shaper enabled.
The Port 2 page is shown below with 8 Queues Weighted Scheduler Mode selected:
Queue Scheduler
Weight: Controls the weight for this queue. Valid values are 1-100. This parameter is only shown if "Scheduler
Mode" is set to "Weighted".
Percent: Shows the weight in percent for this queue. This parameter is only shown if "Scheduler Mode" is set to
"Weighted".
Port Shaper
Enable: Controls whether the port shaper is enabled for this switch port.
Rate: Controls the rate for the port shaper. This value can be 100-13107100 when "Unit" is kbps, and 1-13107
when "Unit" is Mbps. The rate is internally rounded up to the nearest value supported by the port shaper.
Unit: Controls the unit of measure for the port shaper rate as kbps or Mbps.
